Montures & Accessoires > Montures > Equatorial avec GoTo > Avalon > M-Uno > Monture Avalon M-UNO WiFi
N° d'article : 70065

Monture M-UNO WiFi

Prix public : 9.400,00 $ Notre prix:
8.100,00 $ TVA incluse, plus frais d'expédition
Trop cher ?
à court terme
expédié sous 3-5 semaines + durée de transport

Description du produit

Malheureusement, la description de l'article n'a pas encore été traduite en français, c'est pourquoi vous trouverez à la place une description en anglais.

The M-Uno Fast Reverse is a portable single arm fork mount devoted to deepsky imaging in the capacity range up to 20 kg (44 lb).

A Mount for deepsky imaging without the needs of meridian flip!

The M-Uno design was developed on the basis of the Linear Fast Reverse, making use of the same technical concepts:

- Fast Reverse technology

- Computer aided design (CAD)

- High quality manufacturing with digital control 5 axes CNC machines (CNC + CAM)

- Absolute quality materials: Anodized aluminium from milled monobloc, stainless steel components and screws, brass components, techno-polymers

Advanced performance

As for the Linear, the motion transmission technology is based on pulley-tooth belt without play, while its peculiar geometry makes easy the imaging at the meridian crossing regardless the typical problem affecting the classic German Equatorial Mounts, for both the risk of touching the tripod and the need of waiting for the object cross the meridian.

With the M-Uno Mount, an object can be finally tracked all night long!

CONTENT PACKAGE

  • Mount Head with StarGO GoTO control system Wi-Fi
  • Power Supply 15V/4A
  • StarGO control Keypad
  • Keypad connection cable
  • Metric Allen Wrench key set
  • Mount Transport Handle
  • Counterweight 0,5 kg with support shaft
  • Losmandy clamp
  • USB flash drive with manuals and software
  • Polar finder and LED illuminator kit Mount
  • Attachment screws
  • Documentation, warranty certificate
  • T-Pod Plate

Spécifications

Capacité


Charge maximale supplémentaire (kg)
25
Type de moteur
Moteurs pas à pas
Platine double
Losmandy-Style
Passe-câble
interne
Contre-poids (exemplaires)
1
Poids de la monture (kg)
15

Particularités


Système GoTo
oui
GPS
-
Interface Autoguider
oui
Raquette de commande
oui
Correction PEC
oui
Interface PC
oui
Pilotage par PC possible
oui
Mobile en rotation
oui

Equipement


<p>trépied
sans trépied
Tablette porte-accessoires
-
Prise allume-cigare
oui
Viseur polaire
oui
Contrepoids (exemplaires)
1
Sac de transport
non
Alimentation électrique
oui
Câble
USB

Trépied


Sac de transport pour statif tripode
non

Données générales


Série
M-Uno
Poids total (kg)
18
Type
Monture
Type de construction
Equatoriale

Domaine d´emploi


Utilisable pour des photos
oui
Utilisable (visuel)
oui
